CFMOTO MTX (N1)

Engine

• Engine Type
• 2-cylinder, inline 4-stroke, liquid-cooled, DOHC, 270° cranksha¬ft
• BORE X STROKE
• 72×55.2 mm
• DISPLACEMENT
• 449.5cc
• MAX POWER
• 32.5kW(44hp)/8500 rpm
• MAX TORQUE
• 44Nm/6250 rpm
• COMPRESSION RATIO
• 11.5:1
• FUEL SYSTEM
• BOSCH EFI
• TRANSMISSION
• CF-SC slipper clutch, 6-speed, wet, multi-plate
• STARTER
• ELECTRIC

Sistem Enjin

• Length x Width x Height
• 2,210×870×1430 mm
• Front Tyre
• 90/90 R21 CST
• Rear Tyre
• 140/70 R18 CST
• Dry Weight(kg)
• 175
• Wheelbase(mm)
• 1,505
• Seat Height
• 820mm / 800mm available by change linkage bolt position
• (870mm with accessory tall seat)
• Ground Clearance(mm)
• 220
• FUEL CAPACITY(Liter)
• 17.5L

Sistem Bahan API

• Frame Type
• Tubular steel frame
• Front Suspension
• KYB, ¬41 upside down suspension,
• compression and damping adjustable
• Rear Suspension
• KYB, multi-link rear suspension, preload, compression and rebound adjustable
• Front Brake
• 320mm single disc, four-piston caliper, J.Juan
• Rear Brake
• 240mm single disc, single-piston caliper, J.Juan
• Battery
• 12V 11.2Ah
