HONDA WAVE DASH 125

Engine

• Type Single Cylinder, Air Cooled, OHC 4-Stroke
• Displacement 124.89cm³
• Bore X Stroke 52.4mm X 57.913mm
• Compression Ratio 9.3:1
• Max. Power 7.35 kW / 8,000 rpm
• Max Torque 9.54 N.m / 6,500 rpm Engine Oil Capacity 0.7 ℓ (After draining), 0.9 ℓ (After disassembly)

Electrical System

• Starter Kick Starter with Electric Auto Start
• Battery Capacity 3.0 A.h (10HR)
• ACG Output 12 V

Fuel System

• Type PGM-FI (Programmed Fuel Injection)
• Fuel Tank Capacity 4ℓ

Chasis

• Frame Type Back Bone
• Dimensions (L x W x H) 1,894mm X 707mm X 1,108mm
• Wheelbase 1,237mm
• Seat Height 767mm
• Ground Clearance 142mm
• Curb Weight 105kg
• Suspension, Wheels & Brakes

Suspension, Wheels & Brake

• Suspension Type Front Telescopic Fork
• Rear Swing Arm with Double Suspension
• Tyre Front 70/90 – 17M/C (38P) (Tubeless)
• Rear 80/90 – 17M/C (50P) (Tubeless)
• Brakes Front Hydraulic Single Disc
• Rear Hydraulic Single Disc
