YAMAHA NMAX 155

Sistem Enjin

• Type: Single Cylinder, Liquid-Cooled, 4-stroke, SOHC, 4-valve

• Displacement: 155 cm³

• Bore x Stroke: 58.0 mm x 58.7 mm

• Compression Ratio: 11.6 : 1

• Maximum Power: 11.3 kW (15.4 PS) / 8,000 r/min

• Maximum Torque: 13.9 Nm (1.4 kgf·m) / 6,000 r/min

• Lubrication System: Force-Feed Lubrication, Wet Sump

• Fuel Supply System: Fuel Injection

• Ignition System: TCI

• Starting System: Electric Starter

• Fuel Tank Capacity: 7.1 L

Casis

• Overall Length: 1,935 mm

• Overall Width: 740 mm

• Overall Height: 1,160 mm

• Seat Height: 765 mm

• Wheelbase: 1,340 mm

• Minimum Ground Clearance: 125 mm

• Wet Weight: 130 kg

Suspensi, Roda dan Brek

• Front Brake: Hydraulic Single Disc, Ø 230 mm

• Rear Brake: Hydraulic Single Disc, Ø 230 mm

• Front Suspension: Telescopic

• Rear Suspension: Unit Swing

• Front Tire: 110/70-13M/C 48P Tubeless

• Rear Tire: 130/70-13M/C 63P Tubeless
