YAMAHA Y16ZR

Sistem Enjin

• Type Sejukan Cecair, 4-Lejang, SOHC, 4-Injap
• Cylinders Silinder Tunggal
• Bore x Stroke 58.0 x 58.7mm
• Compression Ratio 10.5 : 1
• Maximum Horsepower 13.2kW (9,500rpm)
• Maximum Torque 14.4Nm(8,000rpm)
• Starting System Elektrik
• Lubrication System Takungan Basah
• Engine Oil Capacity 1.10L
• Fuel Tank Capacity 5.4L
• Fuel System Suntikan Bahan Api
• Ignition System TCI
• Battery Type 12V 3.5Ah

Casis

• Frame Type Backbone
• Overall Length 1975mm
• Overall Width 665mm
• Overall Height 1,085mm
• Wheelbase 1290mm
• Minimum Ground Clearance 150mm
• Weight 119 kg

Suspensi Roda dan Brake

• Front Cakera Tunggal Hidraulik dengan ABS
• Rear Cakera Tunggal Hidraulik
• Front Suspension Type Teleskopik
• Rear Suspension Type Lengan Buai
• Front Tyre : 90/80-17M/C (46P)
• Rear Tyre : 120/70-17M/C (58P)
