ZEEHO AE4

Motor

• Hub Motor

Battery

• Lithium battery
• 74 V
• 27 Ah

Max Speed

• European version : 45km/h (factory state)
• International version : 65km/h

Rated Power

• 1.6kW

Capacity

• 74V27Ah (Second battery optional)

Peak Power

• 3kW

Max Range

• 63km (WMTC)

Acceleration

• 0-30km/h≤3.5s

Frame

• Steel tube

Grade Ability

• 15°

Brake

• front: ∅220mm disc with opposed 2-piston caliper
• rear: ∅190mm disc with opposed 2-piston caliper

Suspension

• front: hydraulic
• rear: twinshock, spring damper, adjustable

ABS/CBS

• ABS (only for International version and AE4 ABS of European version)

Tires

• front: 80/90-12
• rear: 100/80-12

Dimension

• Width : 743 mm
• Height : 1154 mm
• Length : 1910 mm
• Wheel Base : 1340mm
• Kerb Weight : 94k kg
• Ground Clearance : 130 mm
• Seat Height : 770 mm
